Seafood food speed line IQF Processing plant wholesale price potatoes frozen french fries production
Model:SSD-200/SSD-300/SSD-500/SSD-1000
SSD-300 scheme design:
Internal operating temperature: +35℃~-35℃
Cold product feeding temperature: & LT;25℃ (central temperature)
Frozen product discharge temperature: -20℃ (central temperature)
Freezing time: adjustable from 15 to 45 minutes
Energy saving measures: The inlet and outlet of the material shall be equipped with a wind shield to avoid the loss of cooling capacity caused by the direct blowing of the cold air out of the insulation layer and effectively reduce the loss of cooling capacity. In addition, a separate buffer room can be set.
The external dimension of the monofreezer is 12600×3500×2400 (mm), and other production dimensions can be customized (example: 22600×3500×2400 (mm)).
Features and performance:
1. The design and production of the whole equipment shall comply with the REQUIREMENTS of HACCP to ensure food hygiene and safety, which can enable food processing enterprises to pass the HACCP certification smoothly and obtain food export pass.
2. The frame structure adopts stainless steel SUS304, all of which are argon arc welding.
3. The evaporator is aluminum tube and aluminum sheet with large distance structure to make the defrosting interval long.The use of large fin, so that the frost cleaning is very convenient, in line with the food hygiene conditions.Large area aluminum alloy finned bushing expansion process, high heat transfer efficiency.Thick wall tube of evaporator tube, pass pressure test of 24kg/cm2.
4. Way of frost washing;Uniform water frosting is controlled by external water valve.
5. The library is made of 304 stainless steel, which is beautiful and generous overall.The thickness of the storehouse plate is 120mm, the bulk density is ≥40kg/m, and the four corners are made of special corner plate, which is formed once, with good insulation performance. The inlet and outlet of the material is equipped with buffer room, which can effectively reduce the power consumption.
6. The bottom of the storehouse plate has a certain inclination degree, and is equipped with a drain hole for easy cleaning, so as to ensure that there is no sanitary dead Angle inside the equipment.
| Frozen product name: | Pastry/fish/meat/seafood |
| Packaging: | No packaging |
| Placement: | On the conveyor belt |
| Cold product feeding temperature: | <25℃ (central temperature) |
| Freezing time: | Adjustable 15-45min |
| Freezing temperature: | -35℃ |
| Cooling capacity: | 40KW (+35℃/-50℃) |
| Freezing capacity: | 300KG/Hour |
Our company focuses on the production and processing of food machinery, provides customized services according to the needs of different programs, and develops long-term services and cooperation with Europe, Asia, South America and other regions and countries.
Zhengzhou Zhiyin Industrial Co., LTD is a professional manufacturer integrating meat processing equipment and vegetable cleaning equipment production and sales, has formed a set of raw material supply, product development, process design, finished product inspection, production and operation, storage and transportation, technical services as one of the perfect operating system.
Mainly engaged in sandwich pot series, cooking pot series, mixing pot series, meat processing equipment, vegetable cleaning equipment. The company has advanced processing center, laser cutting equipment, shear plate bending equipment and a full set of testing equipment. The main products are: sandwich pot, cold powder machine, rolling kneading machine, chopping and mixing machine, mixing stuffing machine, meat mincer, enema machine, vegetable cleaning machine, desalination machine, pasteurization machine, vibrating screen, flexible packaging blow-dry machine, etc.
Email:
Sale@Frenchfriesline.com
Wechat/WhatsApp:+86 15249674563
Wechat/WhatsApp:+86 15249674563
1. Why do you choose Huayuan Food Machinery?
We have 9 years of production and development experience, high quality products, superior program design, good reputation has become the elements of the company.
2. Is the design scheme free of charge?
We design independent schemes free of charge according to customers' specific requirements, and design CAD drawings according to the actual application workshop.
3. Production cycle?
We design independent schemes free of charge according to customers' specific requirements, and design CAD drawings according to the actual application workshop.
4. After-sales service
We will guide the installation online and provide video and graphic information. If necessary, we will arrange technicians to install the machine on site. The after-sales service of the motors configured for our products is one year.
