Industrial quick-freezing machine for food Seafood meat low temperature quick-freezing machine

Industrial quick-freezing machine for food Seafood meat low temperature quick-freezing machine
Products Inquiry
Click Refresh Verification Code

huayuan food machine (1).jpg

Automatic Frozen French Fries Packing Machine for Frozen Food,Small Snack Food Potato Plantain Banana Chips Packaging machine


Vegetables brush washing machine


Freezing machine (3).jpg

Industrial quick-freezing machine for food Seafood meat low temperature quick-freezing machine

Voltage:220V/380V, 3N/380V/50HZ

Power:15kw

Dimension(L*W*H):4000*1200*1300mm

Weight:1200kg

Warranty:1 Year

After-sales Service Provided:Online support

Application fields:Vegetable processing plant, Cooking oil factory, Fruit processing plant, Snack food factory, Frozen food Factory

Machinery Function:Making potato chips/Seafood/Meat

Raw material:Milk, Corn, Fruit, Nuts, Soybean, Flour, Vegetables, Water

Output product name:Frozen food

Key Selling Points:High Productivity

Name:Industrial Food Freezing Machine

Usage:Industrial Seafood Quick-Freezing Iqf Machine

Application:Food Quick Frozen Machine

Capacity:50-100kg/hr

Freezing time:5-50(Continually Adjustable)

Function:Meat Fish Seafood

Freezing temperature:+35℃~-45℃

Overall dimension:
3000x1700x1800mm
Trolley Quantity:
4 (304 stainless steel) 2 in cabinet with 15 plates in each trolley
Trolley size:
Customized according to customer pallet size
Air cooler DJ-80 evaporation area:
80m³
Cooling consumption:
12KW
Compressor power:
8KW (10P)
Compressor brand:
Shenyang Glun
Air cooler:
Stainless steel food grade material
Refrigerant:
R22
Freon:
2 bottles
Power:
380 V
Frost:
380 v
Insulation:
Polyurethane foam
Cover stainless steel plate:
304 stainless steel wire drawing plate
Number of universal wheels:
6 sets at the bottom


304 Stainless Steel Industrial quick-freezing machine for food Seafood meat low temperature quick-freezing machine

Freezing cabinet is a kind of low temperature refrigeration and freezing equipment for deep freezing. Freezers are used for a wide variety of purposes, from the food industry to the medical industry and so on. The same as the principle of air conditioning, the quick-freezing cabinet is to use the compressor to compress the gaseous Freon into gaseous Freon of high temperature and high pressure, and then send it to the condenser for heat dissipation to become liquid Freon of normal temperature and high pressure, so the condenser blows out hot air. Then it goes to the capillary and enters the evaporator. As the space of Freon from the capillary to the evaporator increases suddenly and the pressure decreases, the liquid Freon will vaporize and become the low-temperature Freon in the gaseous state, thus absorbing a lot of heat, and the evaporator will get cold. The cooling in the freezer can be realized by refrigeration or air cooling.

freezing machine (8).jpg

vegetable blanching machine frozen fruit and vegetable blanching machine_20.jpg

huayuan food machine (19).jpg

Zhengzhou Zhiyin  Industrial Co., LTD is a professional manufacturer integrating meat processing equipment and vegetable cleaning equipment production and sales, has formed a set of raw material supply, product development, process design, finished product inspection, production and operation, storage and transportation, technical services as one of the perfect operating system.
Mainly engaged in sandwich pot series, cooking pot series, mixing pot series, meat processing equipment, vegetable cleaning equipment. The company has advanced processing center, laser cutting equipment, shear plate bending equipment and a full set of testing equipment. The main products are: sandwich pot, cold powder machine, rolling kneading machine, chopping and mixing machine, mixing stuffing machine, meat mincer, enema machine, vegetable cleaning machine, desalination machine, pasteurization machine, vibrating screen, flexible packaging blow-dry machine, etc.

Can be widely used in all kinds of meat products, soy products, dairy products, egg products, seafood, beverage products, snack food sterilization, and agricultural products, herbal processing equipment.

Email:Sale@frenchfriesline.com

Wechat:+86 15249634567

WhatsApp:+86 15249634567

Our company focuses on the production and processing of food machinery, provides customized services according to the needs of different programs, and develops long-term services and cooperation with Europe, Asia, South America and other regions and countries.

vegetable blanching machine frozen fruit and vegetable blanching machine_29.jpg


1. Why do you choose Zhiyin Food Machinery?

We have 9 years of production and development experience, high quality products, superior program design, good reputation has become the elements of the company.

2. Is the design scheme free of charge?

We design independent schemes free of charge according to customers' specific requirements, and design CAD drawings according to the actual application workshop.

3. Production cycle?

We design independent schemes free of charge according to customers' specific requirements, and design CAD drawings according to the actual application workshop.

4. After-sales service

We will guide the installation online and provide video and graphic information. If necessary, we will arrange technicians to install the machine on site. The after-sales service of the motors configured for our products is one year.
